• Tubular positive plates: Robust tubular plates consisting of a lead calcium antimony-free alloy optimized for high corrosion resistances
• Pasted negative plates: Grid plate construction consisting of lead calcium alloy
• Separators: Micro porous and robust, for electrical separation of the positive and negative plates and optimized for low internal resistance
• Housing: ABS, on request flame retardant ABS.
• One way relief valve: operates at low pressure and fitted with flame arrestor, release gas in case of excess pressure and protects the cell against atmosphere.
• Poles: Screw connection for easy and safe assembly and maintenance-free connection with excellent conductivity.
• Post seals: extremely high integrity post seal design to prevent electrolyte leakage and terminal corrosion.
• Connectors: flexible fully insulated cable connectors screwed to the terminal with an insulated screw having a probe hole on the top for electrical measurement.
• Electrolyte: Gel structure.
• Proprietary Fixed Orifice Plate pasting technology applying active materials on both sides of the grid for consistent cell to cell performance, higher capacity and uniform grid protection.
| TECHNICAL INFORMATION | ||
| Nominal Voltage | 2V | |
| Capacity(10HR, 25°C) | 200Ah | |
| Dimension | Length | 302±2mm(11.78inch) |
| Width | 175±2mm(6.83inch) | |
| Height | 330±2mm(12.87nch) | |
| Approx. Weight | 36kg (79.2lbs)±4% | |
| Operating temperature range | -20°C~50°C(-4°F~122°F) | |
| Standard charging method(25°C) | Current | 0.5A |
| Time | 5~10H | |
| Quickly charging method(25°C) | Current | 2.5A |
|
|
Time | 1H |
| Terminal material | Lead/Copper | |
| Container material | ABS | |
