• Virgin Pure Lead Tin and thick positive plate technology design - 15 years design life @ 20˚C(68˚F);
• Valve regulated lead acid battery (VRLA);
• Optimized high-compression Absorbed Glass Mat (AGM) materials significantly enhance performance, greater than 99% recombination efficiency;
• Advanced triple stage unique terminal sealing design to ensure leak free operation;
• Operates at a low internal pressure;
• Heavy duty M6/M8 copper plated terminals provide maximum performance and easy installation, reduce maintenance and increase safety;
• Advanced lead tin low-calcium alloy, reduces grid corrosion and promotes long battery life;
• Designed to withstand extreme temperature degrees and performance without degradation;
• Over-sized, through the partition inter-cell welds provide low resistance connections.
• Multi-cell design for ease of installation and maintenance;
• Horizontal or vertical operation.
• Fixed Orifice Plate Pasting technology applying active materials on both sides of the grid for consistent performance.
| TECHNICAL INFORMATION | ||
| Nominal Voltage | 2V | |
| Capacity(10HR, 25°C) | 200Ah | |
| Dimension | Length | 330±2mm(12.88inch) |
| Width | 171±2mm(7.67inch) | |
| Height | 214±2mm(8.35nch) | |
| Approx. Weight | 29.3kg (64.46bs)±4% | |
| Operating temperature range | -20°C~50°C(-4°F~122°F) | |
| Standard charging method(25°C) | Current | 0.5A |
| Time | 5~10H | |
| Quickly charging method(25°C) | Current | 2.5A |
|
|
Time | 1H |
| Terminal material | Lead/Copper | |
| Container material | ABS | |
