♦Maintenance-Free ,Absorbent Glass Mat Technology
♦Low Self Discharge
♦Long Designed service Life ,Deep Cycles
♦Excellent Discharge Performance
♦Environment Friendliness
♦Wide suitability of ambient temperature range
Applications :
♦Hybrid and off grid solar power system
♦ UPS battery backup
♦Wind solar energy system
♦ Signal system , emergency lighting system , security system
♦Telecommunication Equipment
♦Power station and plant room
Specifications
|
Nominal Voltage |
12 V |
|
|
Capacity(10HR, 25℃) |
9Ah |
|
|
Dimension |
Length |
135±2mm |
|
Width |
76±2mm |
|
|
Height |
135±2mm |
|
|
Approx. Weight |
2.8kg (6.61lbs)±5% |
|
|
Operating temperature range |
-20℃～50℃(-4℉～122℉) |
|
|
Standard Charging method (25℃) |
Current |
0.9A |
|
Time |
5~10h |
|
|
Quickly Charging method (25℃) |
Current |
4.5A |
|
Time |
1h |
|
|
Terminal material |
Lead |
|
|
Container Material |
ABS |
|
