♦Safety seal ,Deflating system ,Simple maintenance ,long lasting ,Stable quality and high reliability
♦Gelled electrolyte made by mixing sulfuric acid with silica fume.
♦The electrolyte is gel like ,immobile and does not leak ,enabling uniform reaction of each part of the plate .
♦High rate discharge performance due to tight assembly technology
♦Strong heat dissipation and wide operating temperature range
♦Avoid acid mist being separated out , environment friendliness
♦Efficient venting system release excessive gas automatically
Applications :
♦Hybrid and off grid solar power system
♦ UPS battery backup
♦Wind solar energy system
♦ Signal system , emergency lighting system , security system
♦Telecommunication Equipment
♦Power station and plant room
Specifications
|
Nominal Voltage |
12 V |
|
|
Capacity(10HR, 25℃) |
32Ah |
|
|
Dimension |
Length |
195±2mm (7.68inch) |
|
Width |
130±2mm (5.12inch) |
|
|
Height |
155±2mm (6.1inch) |
|
|
Approx. Weight |
10kg (22.1lbs)±5% |
|
|
Operating temperature range |
-20℃～50℃(-4℉～122℉) |
|
|
Standard Charging method (25℃) |
Current |
1.2A |
|
Time |
5~10h |
|
|
Quickly Charging method (25℃) |
Current |
6A |
|
Time |
1h |
|
|
Terminal material |
Lead |
|
|
Container Material |
ABS |
|
